Rich Solar NOVA 3K | 3000 Watt (3kW) 48 Volt Off-Grid Hybrid Solar Inverter
The Rich Solar NOVA 3K is a compact yet powerful 3000W off-grid hybrid inverter engineered for high-efficiency solar energy systems. Designed for residential. cabin. RV. or light commercial applications. it delivers clean pure sine wave output with excellent efficiency and reliable protection. Equipped with an integrated MPPT charge controller. it maximizes your solar harvest while offering a range of intelligent features like configurable input prioritization. optional Wi-Fi/GPRS monitoring. and full BMS support via CAN or RS485. Its lightweight. space-saving form factor makes it ideal for installations with limited space. For users looking to scale. the NOVA 3K supports parallel operation of up to 6 units. making it easy to expand your system as energy needs grow.
Key Features
3000W Pure Sine Wave Output:Clean and stable power ideal for sensitive electronics and appliances.
Integrated MPPT Charge Controller (4500W Max PV):Maximizes solar input efficiency with 98% peak performance.
Lightweight & Compact Design:High-frequency inverter design makes it easy to install in tight spaces.
Battery & Generator Compatible:Works with 48V battery systems and accepts utility or generator power.
Expandable to 6 Units:Parallel operation allows up to 18kW total capacity for larger setups.
Specifications
Rated Power: 3000VA / 3000W
Waveform: Pure Sine Wave
Peak Efficiency (Inverter): 93%
Peak Efficiency (Solar): 98%
Transfer Time: 1020 ms
AC Voltage (Battery Mode): 120VAC 5%
Weight: 25.4 lb
Dimensions: 13.8L x 5.1W x 18.0H
Max PV Array Power: 4500W
MPPT Range: 60115VDC
Open Circuit Voltage (VOC): 145VDC
Max Solar Charge Current: 80A
AC Input Voltage: 120VAC
Selectable Input Range:
95140 VAC (Personal Computers)
65140 VAC (Home Appliances)
Charge Current: 40A
Frequency: 50/60Hz (Auto Sensing)
Humidity: 5�% RH (non-condensing)
Operating Temp: 0C 55C
Storage Temp: -15C 60C
What's in the Box
1 Rich Solar NOVA 3K Inverter
1 User Manual
1 Mounting Hardware Kit
